Injection Machine Soft Plastic 1300T
Specification:
| | | | GS1308V |
| A | B | C | D |
| INJECTION UNIT | Screw Diameter | mm | 110 | 120 | 130 | 140 |
| Screw L/D Ratio | L/D | 24 | 22 | 20.3 | 18.9 |
| Shot Size(Theoretical) | cm3 | 6272 | 7464 | 8760 | 10160 |
| Injection Weight | g | 5708 | 6793 | 7972 | 9246 |
| Injection Rate | g/s | 698 | 830 | 974 | 1130 |
| Plasticizing Capacity | g/s | 137 | 168 | 198 | 229 |
| Injection Pressure | Mpa | 213 | 179 | 152 | 131 |
| Screw Speed | rpm | 0-90 |
| CLAMPING UNIT | Clamp Tonnage | KN | 13080 |
| Toggle Stroke | mm | 1400 |
| Space Between Tie Bars | mm | 1350*1280 |
| Max.Mould Height | mm | 1300 |
| Min.Mould Height | mm | 600 |
| Ejector Stroke | mm | 350 |
| Ejector Tonnage | KN | 215 |
| Ejector Number | piece | 25 |
| OTHERS | Max.Pump Pressure | Mpa | 16 |
| Pump motor Power | KW | 37+37+23+25+1.5 |
| Heater Power | KW | 85.55 |
| Machine Dimension(L*W*H) | m | 13.33*3.06*2.80 |
| Machine Weight | t | 62 |
| Hopper Capacity | Kg | 100 |
| Oil Tank Capacity | L | 1300 |
Plastic Injection Machine:
Plastic Injection Machine is suitable for using PET Preform Mold, Plastic Cap Mold, Plastic Bottle Mold, Plastic Cup Mold, Plastic Fork Mold, Plastic Spoon Mold, Preform Mold for Jars, Transportation Plastic Pallet Mold...
We can manufacture preform mold according to your demands, with more than 10 years experience and our injection machines have passed CE certificated.
Our Injection molding machine ranges from 68T-3000T, with high precision and rigidity, fast respons and energy efficiency.
Feature: 1. One step fast molding
2. Servo Motor can optimize the match of energy demands
3. High speed production with multi cavities on different preform molds
4. Save energy, power, labor and eco-friendly
5. Meet various kinds of preform mold project
.FAQ:
Q1: Are you a trading company or a manufactory?
A1: We are a manufactory, we supply the factory price with good quality, welcome to visit !
Q2: What’s your guarantee or the warranty of the quality if we buy your machines?
A2: We offer you high quality machines with 1 year guarantee and supply life-long technical support.
Q3: When can I get my machine after I paid?
A3: The delivet time is based on the exact machine you confirmed.
Q4: How can I install my machine when it arrives?
A4: We will send our engineers to your factory to install the machines and train your staff how to operate the machines.
Q5: How about the spare parts?
A5: After we deal down all the things , we will offer you a spare parts list for your reference.
